0.17mm SPCC Tinplate Steel Sheet T2 For Oil Cans Making

Product Categories
Jiangsu Senyilu Metal Material Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

0.17mm SPCC Tinplate Steel Sheet T2 For Oil Cans Making

  • 1
  • 2
  • 3

Brand Name : SYL

Model Number : tinplate

Certification : CE ISO

Place of Origin : CHINA

MOQ : 5ton

Price : ＄800-1000/Metric Ton

Payment Terms : T/T, Western Union, L/C, D/A, D/P

Supply Ability : 2000 Ton/Tons per Month

Delivery Time : 7-15 work days

Packaging Details : Standard seaworthy export packing or as customer demands

Product name : Factory Price SPCC Tinplate Steel Sheet Tin Plate for Oil Cans Making

Technique : Cold Rolled

Thickness : 0.16mm; 0.17mm; 0.18mm; 0.19mm; 0.20mm

Surface : Stone Finished or Bright Finish

Standard : JIS

Colour : Tin colour

Material : MR; SPCC

Temper : T1, T2, T3, T4, T5

Contact Now

Factory Price SPCC Tinplate Steel Sheet Tin Plate for Oil Cans Making

Product Introduction

The basic plate of this tinplate sheet is SPCC, as we all know tin layer works as a e substance between the metal and the food. Tin helps utensils made of brass and copper increase its conductivity which also reduces the fuel cost. With regular intervals re-tinning, it also maintains the taste of the food.Tin is a silver-white metal that is soft, ductile and malleable. Due to this flexibility, tin can be molded and stretched into a variety of shapes without cracking. Tin is also considered to be non-toxic, conductive and resistant to corrosion.

Specifications

Product Name

 Factory Price SPCC Tinplate Steel Sheet Tin Plate for Oil Cans Making

Standard

JIS

Material

MR

Grade

Prime

Annealing

BA/ CA

Thickness

0.16-1.0mm

Width

As customer required and ordered

Temper

T1, T2, T3, T4, T5, DR-7m, DR-8, DR-8m

Coating(g/m2)

1.1/1.1 2.0/2.0 2.8/2.8

Surface Finish

Stone finish; Bright finish

Packaging

Standard export packing or according to customer's requirements.

Payment

T/T or L/C

JIANGSU SENYILU METAL MATERIAL CO., LTD supplies different specifications of Double reduced (DR) tinplate and Single reduced (SR) tinplate.

It can be used in many parts,such as food can, oil cans and caps. At present, tinplates have been exported to many countries around the world, such as Egypt, , Myanmar, Thailand and other countries. It is widely used in food packaging and chemical product packagings. We can provide high-quality tinplates that meet international standards.

0.17mm SPCC Tinplate Steel Sheet T2 For Oil Cans Making

Coating Structure

0.17mm SPCC Tinplate Steel Sheet T2 For Oil Cans Making

Production Process

0.17mm SPCC Tinplate Steel Sheet T2 For Oil Cans Making

Mechanical Properties

Temper Grade

Hardness(HR30Tm)

Yield Strength(MPa)

T-1

49±3

330

T-2

53±3

350

T-3

57±3

370

T-4

61±3

415

T-5

65±3

450

T-6

70±3

530

DR-7M

71±5

520

DR-8

73±5

550

DR-8M

73±5

580

DR-9

76±5

620

DR-9M

77±5

660

DR-10

80±5

690

Coating Weight

Former Coating Designation

Nominal Coating Weight
(g/m2)

Minimum average Coating Weight (g/m2)

10#

1.1/1.1

0.9/0.9

20#

2.2/2.2

1.8/1.8

25#

2.8/2.8

2.5/2.5

50#

5.6/5.6

5.2/5.2

75#

8.4/8.4

7.8/7.8

100#

11.2/11.2

10.1/10.1

25#/10#

2.8/1.1

2.5/0.9

50#/10#

5.6/1.1

5.2/0.9

75#/25#

5.6/2.8

5.2/2.5

75#/50#

8.4/2.8

7.8/2.5

75#/50#

8.4/5.6

7.8/5.2

100#/25#

11.2/2.8

10.1/2.5

100#/50#

11.2/5.6

10.1/5.2

100#/75#

11.2/8.4

10.1/7.8

125#/50#

15.1/5.6

13.9/5.2

Applications

Tinplate is primarily used for packaging foodstuffs and beverages, but it is also used in containers for oils, grease, paints, polishes, chemicals and many other products. Aerosol containers and caps and closures are also made from ETP.

0.17mm SPCC Tinplate Steel Sheet T2 For Oil Cans Making

0.17mm SPCC Tinplate Steel Sheet T2 For Oil Cans Making

FAQ:

Q1. What are your company's main products ?

A1: Our main products are stainless steel plate/sheet, coil, round/square pipe, bar, channel, etc.

Q2. How do you control quality ?

A2: Mill Test Certification is supplied with shipment, Third Party Inspection is available. and we also get ISO,SGS.

Q3. What are the advantages of your company ?

A3: We have many professionals, technical personnel, more competitive prices and best after-dales service than other stainless steel companies.

Q4. How many coutries you already exported ?

A4: Exported to more than 50 countries mainly to Egypt, , Myanmar, Thailand etc.

Q5. Can you provide sample ?

A5: We can provide the samll samples in stock for free, as long as you contact us.

Customized samples will take about 5-7days.
